| Parameter | Value | |
|---|---|---|
| The chip type |
Charging IC
|
|
| Input Voltage |
4V to 6.5V
|
|
| Current |
1A; 40µA
|
|
| Charging saturation voltage |
4.2V
|
|
| Type of battery |
Lithium Battery
|
|
| Number of Cells |
1
|
|
| Temperature |
-40°C to 85°C
|
|
| Battery temperature detection |
Not supported
|
|
| 0v battery charge |
Not supported
|
|
| Features |
Automatic recharge; Constant voltage charging; Programmable charging current; Soft-start; Under-voltage lockout
|
|
| Battery chemistry |
Lithium Ion
|
|
| Current charging |
Constant - Programmable
|
|
| Fault protection |
Over Temperature
|
|
| Battery pack voltage |
4.2V
|
|
| Supply Voltage Maximum |
8V
|
|
| Mounting Type |
SMD
|
|
| Package |
8-ESOP; 8-SOIC (0.154", 3.90mm Width) Exposed Pad
|
Document details will be displayed in this section.
Compare prices across distributors
| Quantity | LCSC | DigiKey |
|---|---|---|
| 10 |
$0.0486
Total: $0.49
|
Not Available
at this quantity
|
| 100 |
$0.0391
Total: $3.91
|
Not Available
at this quantity
|
| 300 |
$0.0344
Total: $10.32
|
Not Available
at this quantity
|
| 1,000 |
$0.0309
Total: $30.90
|
Not Available
at this quantity
|
| 4,000 |
$0.026
Total: $104.00
|
$0.03162
Total: $126.48
|
| 8,000 |
$0.0246
Total: $196.80
|
$0.03162
Total: $252.96
|
| Qty | Unit Price | Total |
|---|---|---|
| 10 | $0.0486 | $0.49 |
| 100 | $0.0391 | $3.91 |
| 300 | $0.0344 | $10.32 |
| 1000 | $0.0309 | $30.90 |
| 4000 | $0.026 | $104.00 |
| 8000 | $0.0246 | $196.80 |
| Qty | Unit Price | Total |
|---|---|---|
| 4000 | $0.03162 | $126.48 |
