Espressif ESP32-H2-MINI-1-N2

Name: Espressif ESP32-H2-MINI-1-N2
Brand: Espressif
SKU: PS61735078
Availability: Discontinued

802.15.4, Bluetooth, WiFi Bluetooth v5.0, Thread, Zigbee® Transceiver Module 2.4GHz PCB Trace Surface Mount

Datasheet

This product is discontinued

2 distributors in stock 3 distributors MSL 3

Package / Case: 53-SMD Module Voltage: 3V to 3.6V Current: 25mA Power: 18.5dBm

Component Details

Manufacturer Espressif

MPN ESP32-H2-MINI-1-N2

PartSense # PS61735078

Availability 2 in-stock / 3 distributors

Classification

Category Multiprotocol Modules

MSL Level 3

Create a free account to add this component to your workspace, manage stock levels across multiple locations, and organize your bills of materials.

Where to Buy the ESP32-H2-MINI-1-N2

Compare prices across distributors

Quantity	LCSC	DigiKey	Mouser
1	$4.0951 Total: $4.10	$3.69 Total: $3.69	$3.69 Total: $3.69
10	$3.6068 Total: $36.07	$3.184 Total: $31.84	$3.19 Total: $31.90
25	$3.6068 Total: $90.17	$3.0092 Total: $75.23	$2.97 Total: $74.25
30	$3.3147 Total: $99.44	$3.0092 Total: $90.28	$2.97 Total: $89.10
100	$3.0736 Total: $307.36	$2.7692 Total: $276.92	$2.77 Total: $277.00
250	$3.0736 Total: $768.40	$2.7692 Total: $692.30	$2.65 Total: $662.50
500	$2.9114 Total: $1455.70	$2.7692 Total: $1384.60	$2.42 Total: $1210.00
1,000	$2.8372 Total: $2837.20	$2.7692 Total: $2769.20	$2.35 Total: $2350.00

	Parameter	Value
	Components	ESP32-H2
	Interface	Bluetooth v5.0; DMA; GPIO; I2C; I2S; PWM; SPI; Thread; UART; USB; Zigbee
	RF Family/Standard	802.15.4; Bluetooth 5.3; WiFi
	Transmitting Power	18.5dBm
	Input Voltage	3V to 3.6V
	Features	Mesh networking; On-board PCB Antenna
	Receiving Current	25mA
	Send current	112mA
	Sensitivity	-98dBm
	Frequency	2.4GHz
	Type	PCB Trace
	Memory	256kB SRAM
	Mounting Type	SMD
	Package	53-SMD Module
