14V Clamp 2.5A (8/20µs) Ipp Tvs Diode Surface Mount 10-USON (2.5x1)
Create a free account to add this component to your workspace, manage stock levels across multiple locations, and organize your bills of materials.
| Parameter | Value | |
|---|---|---|
| Polarity |
Unidirectional
|
|
| Reverse stand off voltage |
5.5V
|
|
| Clamping voltage |
14V
|
|
| Peak pulse current |
2.5A@8/20us
|
|
| Power |
40W@8/20us
|
|
| Voltage breakdown |
6.5V
|
|
| Reverse leakage current |
10nA
|
|
| Number of Channels |
Four channels
|
|
| Temperature |
-40°C to 125°C
|
|
| Level of protection |
IEC 61000-4-4
|
|
| Type |
ESD
|
|
| Capacitance |
500fF
|
|
| Unidirectional channels |
4
|
|
| Power peak pulse |
40W
|
|
| Power line protection |
Yes
|
|
| Applications |
HDMI; USB
|
|
| Mounting Type |
SMD
|
|
| Package |
10-UFDFN; 10-USON (2.5x1); USON10
|
|
| Type of diode |
TVS array
|
|
| Semiconductor structure |
Unidirectional
|
|
| Version |
ESD
|
|
| Input Voltage |
0V to 5.5V
|
|
| Operating Voltage |
5.5V
|
|
| Pin Count |
10
|
|
| Product range |
TPD4E
|
