Texas Instruments PS87675053 - Bipolar (BJT) Transistor Array 7 NPN Darlington 50V 500mA Surface Mount 16-TSSOP
Images are property of their respective owners, including LCSC, DigiKey, Mouser, TME, element14, Farnell, Newark and Future Electronics
Darlington Transistors

Texas Instruments ULN2003LVPWR

Bipolar (BJT) Transistor Array 7 NPN Darlington 50V 500mA Surface Mount 16-TSSOP

Datasheet
5 distributors in stock 5 distributors MSL 1
Package / Case: 16-TSSOP; 16-TSSOP (0.173", 4.40mm Width); TSSOP Voltage: 3 Current: 1 Temp: -40°C to 85°C
Component Details
Manufacturer Texas Instruments
MPN ULN2003LVPWR
PartSense # PS87675053
Availability 5 in-stock / 5 distributors
Classification
Category Darlington Transistors
Product Status Active
MSL Level 1
