Nexperia PS03460848 - 74HC Series 6 V 3-State Surface Mount 8-Bit Serial Shift Register - DHVQFN-16
Images are property of their respective owners, including LCSC, DigiKey, Mouser, TME, element14, Farnell, Newark and Future Electronics
Shift registers

Nexperia 74HC595BQ,115

74HC Series 6 V 3-State Surface Mount 8-Bit Serial Shift Register - DHVQFN-16

Datasheet
8 distributors in stock 8 distributors MSL 1
Package / Case: 16-DHVQFN (2.5x3.5); 16-VFQFN Exposed Pad; DHVQFN16 Voltage: 2V to 6V Current: 35mA Temp: -40°C to 125°C
Component Details
Manufacturer Nexperia
MPN 74HC595BQ,115
PartSense # PS03460848
Availability 8 in-stock / 8 distributors
Classification
Category Shift registers
Product Status Active
MSL Level 1

Start tracking your inventory today.

Create a free account to add this component to your workspace, manage stock levels across multiple locations, and organize your bills of materials.

  • Inventory visibility
  • Lot & batch tracking
  • Project organization
Parameter Value
Type of integrated circuit
Digital
Core Size
8bit; Latch; Parallel/serial out; Serial input; Shift register; Storage register
Mounting Type
SMD
Package
16-DHVQFN (2.5x3.5); 16-VFQFN Exposed Pad; DHVQFN16
Series
74HC; HC
Temperature
-40°C to 125°C
Input Voltage
2V to 6V
Packaging
Reel; Tape
Kind of output
3-state
Technology
CMOS
Ic output type
CMOS
Supply Voltage Minimum
2V
No of elements
1 Element
Pin Count
16
Logic ic base number
74595
No of bits per element
8 Bit
Supply Voltage Maximum
6V
Shift register function
Parallel; Serial
Logic ic family
74HC
Base number
74HC595
Type
Shift Register; StandardCMOS
Output
Tri-State
Number of elements
1
Number of bits per element
8
Function
Serial to Parallel; Serial-to-Serial or Parallel
Frequency
100MHz
Propagation delay
Output Current
35mA
Resolution
8
Features
Asynchronous clear function; Output enable
