Nexperia PTVS24VZ1UPAZ

ESD Protection Diodes / TVS Diodes PTVS24VZ1UPA/SOT1061/HUSON3

Datasheet
1 distributor in stock 4 distributors MSL 1
Package / Case: 3-HUSON; 3-PowerUDFN Voltage: 24V Current: 1µA Power: No Temp: -40°C to 125°C
Component Details
Manufacturer Nexperia
MPN PTVS24VZ1UPAZ
PartSense # PS16325248
Availability 1 in-stock / 4 distributors
Classification
Category Unidirectional TVS SMD diodes
Product Status Active
MSL Level 1

Start tracking your inventory today.

Create a free account to add this component to your workspace, manage stock levels across multiple locations, and organize your bills of materials.

  • Inventory visibility
  • Lot & batch tracking
  • Project organization
Parameter Value
Polarity
Unidirectional
Reverse stand off voltage
24V
Clamping voltage
28V; 31V
Voltage breakdown
25V; 29V
Reverse leakage current
1µA
Number of Channels
1
Temperature
-40°C to 125°C
Type
TVS; Zener
Unidirectional channels
1
Peak pulse current
150A
Power line protection
No
Applications
General Purpose
Capacitance @ frequency
620pF@1MHz
Grade
Automotive
Qualification
AEC-Q100
Mounting Type
SMD
Package
3-HUSON; 3-PowerUDFN
