BVSS138L Series 50 V 200 mA 3.5 Ohm SMT N-Channel Power Mosfet - SOT-23-3
Create a free account to add this component to your workspace, manage stock levels across multiple locations, and organize your bills of materials.
| Parameter | Value | |
|---|---|---|
| Type of transistor |
N-MOSFET
|
|
| Polarity |
N Channel; Unipolar
|
|
| Drain-Source Voltage |
50; 50V
|
|
| Drain Current |
200; 200mA
|
|
| Power |
225; 225mW; 225mW (Ta)
|
|
| Package |
SC-59; SOT-23-3 (TO-236); SOT23; TO-236-3
|
|
| Gate-Source Voltage |
±20V
|
|
| Drain-Source On-State Resistance |
3.5Ω to 10Ω
|
|
| Mounting Type |
SMD
|
|
| Packaging |
Reel; Tape
|
|
| Transistor Type |
Enhancement; N Channel
|
|
| Type |
N-Channel
|
|
| Technology |
MOSFET (Metal Oxide)
|
|
| Drive voltage |
5V
|
|
| Rds on @ id, vgs |
3.5Ω
|
|
| Vgs @ id |
1.5V@1mA
|
|
| Input capacitance @ vds |
50pF@25V
|
|
| Temperature |
-55°C to 150°C; 150; 150°C
|
|
| Grade |
Automotive
|
|
| Qualification |
AEC-Q101
|
|
| Rds test voltage |
5; 5V
|
|
| Gate Threshold Voltage |
1.5; 1.5V; 1.5V@1mA
|
|
| Transistor case style |
SOT-23
|
|
| Pin Count |
3; 3 Pins
|
|
| Number |
1 N-Channel
|
|
| Capacitance |
25pF; 50pF
|
|
| Reverse transfer capacitance |
5pF
|
|
| Automotive qualification standard |
AEC-Q101
|
|
| On resistance rds |
3.5Ω
|
