Texas Instruments PS08462472 - Buck Switching Regulator IC Positive Fixed 5V 1 Output 3A TO-220-5 Formed Leads
Images are property of their respective owners, including LCSC, DigiKey, Mouser, TME, element14, Farnell, Newark and Future Electronics
Voltage regulators - DC/DC circuits

Texas Instruments LM2596T-5.0/NOPB

Buck Switching Regulator IC Positive Fixed 5V 1 Output 3A TO-220-5 Formed Leads

Datasheet
6 distributors in stock 6 distributors MSL 1
Package / Case: TO-220-5 Formed Leads; TO220-5 Voltage: 4.5V to 40V Current: 3A Temp: -40°C to 125°C
Component Details
Manufacturer Texas Instruments
MPN LM2596T-5.0/NOPB
PartSense # PS08462472
Availability 6 in-stock / 6 distributors
Classification
Category Voltage regulators - DC/DC circuits
Product Status Active
MSL Level 1
