onsemi PS26628243 - Buck, Boost, Buck-Boost Switching Regulator IC Positive or Negative Adjustable 1.23V 1 Output 3A TO-220-5 Formed Leads
Images are property of their respective owners, including LCSC, DigiKey, Mouser, TME, element14, Farnell, Newark and Future Electronics
Voltage regulators - DC/DC circuits

onsemi LM2596TVADJG

Buck, Boost, Buck-Boost Switching Regulator IC Positive or Negative Adjustable 1.23V 1 Output 3A TO-220-5 Formed Leads

Datasheet
5 distributors in stock 8 distributors
Package / Case: TO-220-5 Formed Leads; TO220-5 Voltage: 4.5V to 40V Current: 3A Temp: -40°C to 125°C
Component Details
Manufacturer onsemi
MPN LM2596TVADJG
PartSense # PS26628243
Availability 5 in-stock / 8 distributors
Classification
Category Voltage regulators - DC/DC circuits
Product Status Active

Start tracking your inventory today.

Create a free account to add this component to your workspace, manage stock levels across multiple locations, and organize your bills of materials.

  • Inventory visibility
  • Lot & batch tracking
  • Project organization
Parameter Value
Type of integrated circuit
PMIC
Kind of integrated circuit
DC/DC converter
Package
TO-220-5 Formed Leads; TO220-5
Mounting Type
THT
Packaging
Built-in; Tube
Output
Adjustable
No of outputs
1
Input Voltage
4.5V to 40V
Temperature
-40°C to 125°C
Efficiency
73
Topology
Boost; Buck (Step Down)
Pin Count
5
Output Voltage
1.23V to 37V
Frequency
150kHz
Output Current
3A
Dc dc converter ic case
TO-220
Switching frequency typ
150kHz
Regulator output type
Adjustable
Function
Step-Down; Step-Up; Step-Up/Step-Down; Step-down type
Configuration
Positive or Negative
Number of outputs
1
Synchronous rectifier
No
Quiescent Current
5mA
Features
Cycle-by-cycle current limiting; Overcurrent Protection
